Product Feature
The bottle cap of our 4000BPH Blowing Filling Capping Machine is stored in the lower hopper, and is transferred to the sub-bin through the frequency conversion lifting belt. After the cap is sorted, the cap is supplied to the capping head from the feeding channel. The structure of falling cover is exquisite, and there is no reverse cover sliding. The outer frame of the fuselage is made of stainless steel 304, which complies with GMP requirements. The upper cover part adopts stepped lifting belt, the bottle cap feeding speed is fast, and the noise is low.
Product Description
The 4000BPH Blowing Filling Capping Machine is equipped with advanced process, which has longer service life for use and there is no special need of maintaining. Due to the proper size and compact design, it can be placed everywhere in order to help release space of limited places. As a matter of fact, it is also available of high speed operation. Due to the high and reliable performance, it is generally used for the sealing and sealing equipment of aluminum caps or aluminum plastic caps after the packaging of antibiotic powder injection glass bottles.
| Type: | Filling Machine |
| Condition: | New |
| Packaging Type: | Bottles |
| Packaging Material: | Plastic |
| Automatic Grade: | Automatic |
| Driven Type: | Electric |
| Voltage: | 380V/220V |
| Place of Origin: | Guangzhou, China (Mainland) |
| Dimension(L*W*H): | 6200X4120X3600MM |
| Weight: | 2600KG |
| Certification: | ISO CE |
| Capacity: | 3000BPH |
| Bottle Size: | 5L-10L |
| Material: | 304 Stainless Steel |
| Suitable bottle: | Round and square and other bottles |
| Usage: | Beverage Packaging |
| Processing: | Monobloc Machine |
|
Model |
XLWL14 |
|
Capacity |
6000BPH 5 L PET |
|
Preform ID(Neck) |
Φ20~Φ25 |
|
Preform Height |
≤120mm |
|
Support Ring Outside Diameter |
Φ33~Φ40mm |
|
Bottle Height Under Support Ring |
≤200mm |
|
Round Bottle Diameter Range |
Φ50~Φ70mm |
|
Square Bottle Diagonal Range |
60-72mm |
|
Height Range of Processable Bottle |
100~220mm |
|
Filling Pitch |
36π(113mm) |
|
Electricity Consumption |
Blowing-350kw,3ph+N+G/380VAV/50HZ |
|
Filling -10kw,3ph+N+G/380VAV/50HZ |
|
|
Air Consumption |
Blowing High Pressure |
|
Blowing Low Pressure |
|
|
Filling machine |
|
|
Standard Bottle Discharge Height of the Blower |
130±50mm |
|
Standard Bottle Discharge Conveyor Height |
1150±50mm |
|
Weight |
7520kg |
